| Frame | Carbon MTB Frame FM-650B M20SL,C-T 15"UD 1.5"TOP,FD/Direct Mount ,￠27.2mm/BB-92 QR/135mm/L,or12mm/142mm/L |
| Fork | FS-SID-RL-A3 'FS SID RL 2715SA100 BLK T CRN '27.5"'100MM 'TAPERED '15X100MM 'CROWN |
| Handle Bar | X-Zenith / HB-XR1.0SL, UD Carbon Riser Bar - Super Light Version 31.8x660mm |
| Stem | X-Zenith / ST-XS1.0SL, UD.MAT.31.8*90L Carbon Stem, Carbon Faceflate Red |
| Seat Post | X-Zenith / SP-XS1.0SL, UD/RED Carbon Seat Post,27.2*350mm/L 0 degree/OFFSET |
| Saddle | SLT Silver Nicro Nicro Tubular Embroidered Look: Silver leather cover, Black perf leather top, 3M corners; DNAX Padding |
| Front Derailleur | FRONT DERAILLEUR, FD-M785-E2, DEORE XT, E-TYPE, TOP SWING, DUAL-PULL, CS-ANGLE 66-69, FOR 40-38T(DOUBLE), W/O BB PLATE,W/O BB PLATE FIXING BOLT, BULK |
| Rear Derailleur | REAR DERAILLEUR, RD-M780, DEORE XT SGS 10-SPEED TOP-NORMAL, LOW PROFILE DESIGN, DIRECT ATTACHMENT, BULK |
| Shift Lever: Right | SHIFT LEVER, SL-M780, DEORE XT RIGHT 10-SPEED/ LEFT 2/3-SPEED , INNER W/ OPTICAL GEAR DISPLAY, BULK |
| Brake Lever: | DISC-BRAKE ASSEMBLED SET, DEORE XT BL-M785(L/R),BR-M785(F/R) W/ADAPTER FOR STD FORK, RESIN PAD(W/O FIN), SM-BH90-SB (BLACK), BULK |
| Disc Rotor F/R | ROTOR FOR DISC-BRAKE, SM-RT86, S 160MM 6-BOLT TYPE, BULK |
| Cranketset | FRONT CHAINWHEEL, FC-M785, DEORE XT, HOLLOWTECH 2, FOR REAR 10-SPEED W/BB PARTS, 175MM 40X28T W/O CG, SILVER, BULK |
| Bottom Bracket | Shimano Saint BB71-41A Press-Fit Bottom Bracket MTB (92mm) |
| Cassette Sprocket | ,CASSETTE SPROCKET, CS-M771-10, DEORE XT, 10-SPEED 11-13-15-17-19-21-24-28-32-36T(BK) |
| Chain | CNHG95,CHAIN, CN-HG95, SUPER NARROW HG FOR MTB 10-SPEED |
| Wheel Set: | WH-XX65C Carbon RIM 650B/27.5"WH-XX65C CARBON Clincher 32H*W/27.3*H/31.4 355g W/AGOGO HUB XB-XX5.3 BLK COLOR ,1530g |
| Tire | 27.5 X2.00 M324 170TPI, FOLDING. SILKWORM (360g) |
| Axle / Skewer ,QR | QR-XX2.1 12mm*OLD/142mm *P1.5 AL7075 360Degree China is empty/Lever US:13/21415 TAIWAN:100214698 79g Lever Color/RED |
| Frame : Carbon MTB Frame FM-650B M20SL,C-T 15"UD 1.5"TOP,FD/Direct Mount ,￠27.2mm/BB-92 QR/135mm/L,or12mm/142mm/L | Fork : FS-SID-RL-A3 'FS SID RL 2715SA100 BLK T CRN '27.5"'100MM 'TAPERED '15X100MM 'CROWN |
| Handle Bar : X-Zenith / HB-XR1.0SL, UD Carbon Riser Bar - Super Light Version 31.8x660mm | Stem : X-Zenith / ST-XS1.0SL, UD.MAT.31.8*90L Carbon Stem, Carbon Faceflate Red |
| Seat Post : X-Zenith / SP-XS1.0SL, UD/RED Carbon Seat Post,27.2*350mm/L 0 degree/OFFSET | Saddle : SLT Silver Nicro Nicro Tubular Embroidered Look: Silver leather cover, Black perf leather top, 3M corners; DNAX Padding |
| Front Derailleur : FD-M785-E2, DEORE XT, E-TYPE, TOP SWING, DUAL-PULL, CS-ANGLE 66-69, FOR 40-38T(DOUBLE), W/O BB PLATE,W/O BB PLATE FIXING BOLT, BULK | Rear Derailleur : RD-M780, DEORE XT SGS 10-SPEED TOP-NORMAL, LOW PROFILE DESIGN, DIRECT ATTACHMENT, BULK |
| Shift Lever: Right : SL-M780, DEORE XT RIGHT 10-SPEED/ LEFT 2/3-SPEED , INNER W/ OPTICAL GEAR DISPLAY, BULK | Brake Lever (F/R) : DISC-BRAKE ASSEMBLED SET, DEORE XT BL-M785(L/R),BR-M785(F/R) W/ADAPTER FOR STD FORK, RESIN PAD(W/O FIN), SM-BH90-SB (BLACK), BULK |
| Disc Rotor : ROTOR FOR DISC-BRAKE, SM-RT86, S 160MM 6-BOLT TYPE, BULK | Crankset : FRONT CHAINWHEEL, FC-M785, DEORE XT, HOLLOWTECH 2, FOR REAR 10-SPEED W/BB PARTS, 175MM 40X28T W/O CG, SILVER, BULK |
| Bottom Bracket : Shimano Saint BB71-41A Press-Fit Bottom Bracket MTB (92mm) | Cassette Sprocket : CS-M771-10, DEORE XT, 10-SPEED 11-13-15-17-19-21-24-28-32-36T(BK) |
| Chain : CNHG95,CHAIN, CN-HG95, SUPER NARROW HG FOR MTB 10-SPEED | Wheels : WH-XX65C Carbon RIM 650B/27.5"WH-XX65C CARBON Clincher 32H*W/27.3*H/31.4 355g W/AGOGO HUB XB-XX5.3 BLK COLOR ,1530g |
| Tire : 27.5 X2.00 M324 170TPI, FOLDING. SILKWORM (360g) | Quick Release : QR-XX2.1 12mm*OLD/142mm *P1.5 AL7075 360Degree China is empty/Lever US:13/21415 TAIWAN:100214698 79g Lever Color/RED |
