Frame Road

Gravel -1005D-FM

TSR1005D Full Carbon Monocoque Frame

Size Available   490/520/540/560/580
Head Tube     FSA ACR (1-1/2”)
Seat Post      31.6 mm
Bottom Bracket  BSA/BB30/BB86
Cable Routing   Internal Cabel Routing ( For RB/FD/RD)
Cable Plug      Mechanical and DI2 (2 in 1)
Tire Max       700*50C
O.L.D          TA 12*142mm
Disc brake      Flat mount 140mm or 160mm
Max Chainring   53/39T/50-34T
Weight         1100g (For Size 540/BB86)
ST062 Size      75/90/100/110/120/130
